+2 Images

JCB 2DX

0(0 Reviews)

JCB 2DX is available in the India market with an ex-showroom price of ₹18.00 Lakh. JCB 2DX comes with 49 HP,0.60 cu.m,203 Nm.

₹18.00 Lakh^*

View Price Breakup

EMI starts @

₹33,629/Month^*

Ex-showroom price in

EMI starts @

₹33,629/Month^*

2DX
Price
Variants
Images
Specs
Reviews
Q&A
Videos
EMI
Brochure

JCB 2DX Construction Equipments Specs & Features

49 HP
Power
0.60 cu.m
Bucket Capacity
203 Nm
Maximum Torque

JCB 2DX Latest Update

JCB 2DX is designed with segment best specification, which helps in providing better work efficiency. The Backhoe Loader model from JCB is one the best Construction machines in heavy loading work. The 2DX Backhoe Loader is well-known for its adaptability and performance, having established itself as an effective machine on construction projects. It can accomplish a wide range of tasks with ease and effectiveness. Its engine design prioritizes fuel efficiency without compromising power, ensuring peak productivity. Simultaneously, it reduces operational costs. In addition, the Max. reach at full height of JCB 2DX backhoe loader is 1120 MM. This allows the operators to access elevated areas with ease and confidence.

Base
- 49 HP
- 0.60 cu.m
- 203 Nm
₹18.00 Lakh ^*
View Price Breakup

JCB 2DX Images

JCB 2DX
JCB 2DX

JCB 2DX Specifications

Engine
Loader General Dimension
Backhoe Loader Dimension
Overall Dimension & Weight
Hydraulic system
Service Capacities
Brakes
Tyre
Power Train
General
Dimensions
Swing Mechanism

Engine

ModelKOEL 4R810

CompliantBSIII diesel engine

Gross Power36.4 kW (49 hp)

Loader General Dimension

Dump Height2300 MM

Load Over Height2740

Hinge Pin Height3000

Hinge Pin Forward Reach370

Reach At Ground1300 MM

Max Reach At Full Height Bucket Dumped1120

Below Ground Level Dig Depth790

Rollback At Ground46°

Dump Angle44 Deg.

Bucket Capacity Std0.6

Loader Arm Breakout Force1834 kgf

Max Pay Load800

Maximum Lifting Capacity1620

Backhoe Loader Dimension

Max Dig Depth3020 MM

Reach Ground Level To Rear Wheel Center5140

Reach At Full Height To Slew Center3930

Max Working Height3880

Max Load Over Height2830

Max Lift Capacity1490 Kg

Overall Dimension & Weight

Max Operating Weight5220

Transport Length5500

Width Over Bucket1912 MM

Track Width Rear1420 Mm

Track Width Front1620 Mm

Minimum Ground Clearance330 MM

Height To Top Of Cabin2070

Hydraulic system

Pump TypeGear, double pump

Pump Flow70.4 lpm @ 2200 rpm

Service Capacities

Rear Axle10 Ltr

Hydraulic Oil60

Transmission Oil Capacity16 Ltr

Brakes

ServiceHydraulically actuated, dual line, self-adjusting (compensated), oil immersed, multi-disc type on the rear axle, well protected from dirt, water, etc. Operated through independent pedals linked togeth

Tyre

Standard Front7.5 x 16 -16 PR

Standard Rear12 x 24 - 20 PR, 14.9 x 24 - 12 PR

Power Train

Transmission Make And ModelThe JCB. SS 700 svncbroshuttle transmission. It consistsof a 4-speed, fully Synchromesh, smooth shift gearbox with integral torque convertor and electrically operated reversing shuttle

General

CategoryBackhoe Loader

Power49 HP

Dimensions

Bucket Capacity0.60 cu.m

Swing Mechanism

Maximum Torque203 Nm

JCB 2DX Detailed Overview

Engine
JCB 2DX comes with an engine that generates 36.4 kW (49 hp) and a maximum torque of 203 Nm @ 1400 RPM (as per SAEJ 1995). In addition, this engine gives a new dimension to the work output of this JCB 2DX.

Summary
JCB 2DX engine generates 36.4 kW (49 hp) and a maximum torque of 203 Nm.
Lift Capacity
The JCB 2DX Backhoe Loader has a maximum lifting capability of 1490 kg. This remarkable lifting capacity ensures consistent operation even while handling heavy loads.

Summary
The JCB 2DX Backhoe Loader has a maximum lifting capability of 1490 kg.
