Confused between JCB 3DXandTata Hitachi Shinrai Pro ? Wondering whether you should spend that hard earned money on JCB 3DXandTata Hitachi Shinrai Pro? Don't Worry! We are here to help you choose between these two models. Talking about JCB 3DX, it has been priced at Rs ₹35.00 Lakh. On the other hand, Tata Hitachi Shinrai Pro will cost you more than JCB 3DX.Tata Hitachi Shinrai Pro comes with a price tag of Rs .
Check the detailed comparison for the models below on the basis of features, comfort, power, transmission, suspension and more.
Key Highlights | JCB 3DX | Tata Hitachi Shinrai Pro |
---|---|---|
EX-Showroom Price | ₹35.00 Lakh | Price coming soon |
Base
₹35.00 Lakh
Base
Price coming soon
Model | |
JCB 448 | Cummins 4B3.3T-35.1-C |
Displacement | |
4.8 | 3261 |
Gross Power | |
36 kW (49 hp) @ 2000 RPM | 47 hp |
Maximum Torque | |
240 Nm | 215 NM |
Dump Height | |
2740 MM | 2690 MM |
Load Over Height | |
3320 MM | 3305 MM |
Hinge Pin Height | |
3540 | 3550 mm |
Hinge Pin Forward Reach | |
250 | 360 MM |
Reach At Ground | |
1420 | 1620 |
Max Reach At Full Height | |
1150 MM | 1332 |
Max Reach At Full Height Bucket Dumped | |
780 | 1332 |
Below Ground Level Dig Depth | |
70 | NA |
Rollback At Ground | |
45 deg | NA |
Dump Angle | |
38 | 45 Deg |
Bucket Capacity Std | |
1.1 | 1.1 |
Bucket Breakout Force | |
5700 kgf | NA |
Loader Arm Breakout Force | |
5300 kgf | NA |
Max Pay Load | |
1800 | 1800 |
Maximum Lifting Capacity | |
1490 | NA |
Max Dig Depth | |
4770 MM | 4700 mm |
Reach Ground Level To Swing Center | |
5440 | NA |
Reach Ground Level To Rear Wheel Center | |
6720 | NA |
Reach At Full Height To Slew Center | |
2740 | NA |
Max Working Height | |
5970 | NA |
Max Load Over Height | |
4180 | 3505 |
Bucket Capacity | |
1.26 | 0.09 |
Bucket Capacity Backhoe | |
1.2 | NA |
Bucket Rotation | |
185 deg | 180 Degree |
Dipper Tear Out Force | |
3010 Kgf | NA |
Max Lift Capacity | |
1490 Kg | 1800 Kg |
Max Operating Weight | |
7510 | 7940 |
Transport Length | |
5900 | 6040 MM |
Width Over Bucket | |
2350 MM | NA |
Track Width Rear | |
1730 MM | NA |
Track Width Front | |
1860 MM | NA |
Wheelbase | |
2170 MM | 2130 mm |
Minimum Ground Clearance | |
310 MM | 320 MM |
Height To Top Of Cabin | |
2870 MM | 2940 MM |
Overall Transport Height | |
NA | 3530 |
Pump Type | |
NA | Inline fuel injection pump |
Pump Flow | |
114 lpm | 105 lpm @ 1950RPM |
Engine Oil | |
15 | 11 L |
Rear Axle | |
20 Ltr | NA |
Hydraulic Oil Replacement | |
92 Ltr | NA |
Fuel Tank | |
128 Ltr | 100 L |
Coolant | |
16.5 Ltr | 13 Ltr. |
Hydraulic Oil | |
110 | 65 |
Transmission Oil Capacity | |
17.5 Ltr | 20 Ltr. |
Rear | |
Drive axle rigidly mounted, incorporates JCB Max-Trac torque proportioning differential, driven by short prop shaft from gear box | Carraro axle that is heavy-duty and long-lasting |
Front | |
Steer axle, centrally pivoted, with oscillation angle of 16 | Heavy-duty, non-powered axle |
Type | |
Power track steering | Hydraulic actuation for smooth control |
Turning Circle Diameter Outside Bucket | |
11600 | NA |
Turning Circle Diameter Outside Bucket Not Braked | |
8640 | NA |
Pressure | |
160 bar | 245 Bar |
Service | |
JCB ‘Q’ brakes, hydraulically actuated, dual line, self adjusting (compensated), oil immersed, multi-disc type on the rear axle, well protected from dirt, water etc. requiring no maintenance. Operated | Hydraulically Actuated Disc Brakes |
Parking | |
Hand operated, disc brakes on rear axle input disc. | Hand-operated disc brake on the rear axle |
Hd Rear Optional | |
NA | 14 x 25, 20 PR |
Standard Front | |
9 x 16 - 16 PR | 9.00 x 16 – 16 PR |
Standard Rear | |
16.9 x 28 - 12 PR | 16.90 - 28 - 12 PR |
Transmission Make And Model | |
NA | Equipped with Carraro-make transmission with synchro-shuttle |
Category | |
Backhoe Loader | Backhoe Loader |
